MIL-DTL-83528/10D
REQUIREMENTS:
Material: Type A, B, C, D, E, F, J, K, L, or M.
Part or Identifying Number (PIN): See table I.
Supersession information: See table II.
TABLE I. Dimensions.
Nominal dimensions 2/ 3/
PIN 1/
area (cm ) 4/
001
0.100 (2.54)
0.100 (2.54) 0.034 (0.86)
0.033 (0.84)
0.050
002
0.126 (3.20)
0.110 (2.79) 0.025 (0.64)
0.050 (1.27)
0.079
003
0.126 (3.20)
0.225 (5.72) 0.020 (0.51)
0.075 (1.91)
0.164
004
0.156 (3.96)
0.156 (3.96) 0.062 (1.57)
0.047 (1.19)
0.113
005
0.175 (4.45)
0.156 (3.96) 0.047 (1.19)
0.075 (1.91)
0.152
006
0.327 (8.31)
0.235 (5.97) 0.062 (1.57)
0.115 (2.92)
0.448
1/
"X" in the PIN shall be replaced by the applicable material type. Complete PIN example: M38528/0010A001.
2/
Dimensions are in inches; metric equivalents are given in parenthesis and are for general information only.
3/
Tolerance shall be as follows:
Tolerance
Dimensions
Under .101 (2.57)
± .005 (0.13)
.101 to .200 (2.57 to 5.08)
± .008 (0.20)
.201 to .300 (5.10 to 7.62)
± .010 (0.25)
.301 to .500 (7.62 to 12.70)
± .015 (0.38)
4/
For calculation of volume resistivity (for reference only).
TABLE II. Supersession information.
PIN 1/
PIN 85109X 1/
001
001
002
002
003
003
004
004
005
005
006
006
1/
"X" in the PIN indicates the applicable material type.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Referenced documents. This document references MIL-DTL-83528.
