MIL-DTL-83528/2D
REQUIREMENTS:
Design and interface: See figure 1 and table I. Gaskets described herein are conductive versions of O-
rings covered by AS 3578.
Material: Type A, B, C, D, E, F, H, J, K, L, or M.
Part or Identifying Number (PIN): See table I.
Supersession information: See table II.
TABLE I. Dimensions.
PIN 1/
011
.070 (1.78)
.301 (7.65)
.025
012
.070 (1.78)
.364 (9.25)
.025
013
.070 (1.78)
.426 (10.82)
.025
014
.070 (1.78)
.489 (12.42)
.025
015
.070 (1.78)
.551 (13.99)
.025
017
.070 (1.78)
.676 (17.17)
.025
018
.070 (1.78)
.739 (18.77)
.025
019
.070 (1.78)
.801 (20.34)
.025
020
.070 (1.78)
.864 (21.94)
.025
021
.070 (1.78)
.926 (23.52)
.025
022
.070 (1.78)
.989 (25.12)
.025
024
.070 (1.78)
1.114 (28.30)
.025
026
.070 (1.78)
1.239 (31.47)
.025
028
.070 (1.78)
1.364 (34.65)
.025
114
.103 (2.62)
.612 (15.54)
.054
115
.103 (2.62)
.676 (17.17)
.054
117
.103 (2.62)
.799 (20.29)
.054
126
.103 (2.62)
1.362 (34.59)
.054
128
.103 (2.62)
1.487 (37.77)
.054
132
.103 (2.62)
1.737 (44.12)
.054
134
.103 (2.62)
1.862 (47.30)
.054
142
.103 (2.62)
2.362 (59.99)
.054
145
.103 (2.62)
2.550 (64.77)
.054
155
.103 (2.62)
3.987 (101.27)
.054
1/ "X" in the PIN shall be replaced by the applicable material type. Complete PIN example:
M83528/002A007.
2/ See MIL-DTL-83528/5 for additional sizes.
3/ Tolerance on dimension B shall be ± .003 for parts with a diameter of .070 and below; ± .005 for
diameters from .101 to .200.
4/ Dimensions are in inches; metric equivalents are given in parenthesis and are for general information
only.
5/ Tolerance on dimension C shall be ± .010 for parts from .000 to 1.500 ± .015 for parts from over
1.500 to 2.500; ± .020 for parts from over 2.500 to 4.500.
6/ For calculation of volume resistivity (for reference only).
2
