MIL-DTL-83528/3E
REQUIREMENTS:
Material: Type A, B, C, D, E, F, H, J, K, L, or M.
Part or Identifying Number (PIN): See table I.
Supersession information: See table II.
TABLE I. Dimensions.
PIN 1/
Dimension B
Dimension C
Cross section 4/
Dimension A
area (cm2)
± .005 2/ 3/
± .005 2/ 3/
M83528/003X
± .005 2/
001
.031 (0.78)
.062 (1.57)
.068 (1.73)
.025
002
.047 (1.19)
.094 (2.39)
.078 (1.98)
.041
003
.039 (0.99)
.078 (1.98)
.089 (2.26)
.041
004
.047 (1.19)
.094 (2.39)
.094 (2.39)
.050
005
.031 (0.78)
.062 (1.57)
.100 (2.54)
.037
006
.075 (1.91)
.150 (3.81)
.110 (2.79)
.091
007
.061 (1.55)
.122 (3.10)
.135 (3.43)
.097
008
.059 (1.49)
.118 (3.00)
.156 (3.96)
.109
009
.078 (1.98)
.156 (3.96)
.156 (3.96)
.140
010
.089 (2.26)
.178 (4.52)
.175 (4.45)
.179
011
.094 (2.39)
.188 (4.78)
.188 (4.78)
.203
012
.125 (3.18)
.250 (6.35)
.250 (6.35)
.360
1/
"X" in the PIN shall be replaced by the applicable material type. Complete PIN example: M38528/003A001.
2/
Dimensions are in inches; metric equivalents are given in parenthesis and are for general information only.
3/
For dimensions over .200 the tolerances shall be ± .008.
4/
For calculation of volume resistivity (for reference only).
TABLE II. Supersession information.
Superseded DESC Drawing
PIN 1/
M83528/003X
PIN 85104X 1/
001
002
002
003
003
004
004
010
005
005
006
006
007
007
008
008
009
N/A
010
009
011
012
012
013
1/ "X" in the PIN indicates the applicable material type.
2/ Dimensions of this part are not identical to the superseded part. However, this is an authorized substitution.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
