MIL-DTL-83528/9E
REQUIREMENTS:
Material: Type A, B, C, D, E, F, H, J, K, L, or M.
Part or Identifying Number (PIN): See table I.
Supersession information: See table II.
TABLE I. Dimensions.
Nominal dimensions 2/ 3/
PIN 1/
Cross section area
2
(cm ) 4/
M83528/009X
A (width)
B (height)
001
0.063 (1.60)
0.042 (1.07)
0.017
002
0.095 (2.41)
0.062 (1.57)
0.038
003
0.120 (3.05)
0.075 (1.91)
0.058
004
0.125 (3.18)
0.062 (1.57)
0.050
005
0.156 (3.96)
0.062 (1.57)
0.062
006
0.250 (6.35)
0.062 (1.57)
0.100
007
0.500 (12.70)
0.062 (1.57)
0.242
008
0.500 (12.70)
0.075 (1.91)
0.403
009
0.500 (12.70)
0.188 (4.78)
0.606
010
0.750 (19.05)
0.062 (1.57)
0.300
011
0.880 (22.35)
0.062 (1.57)
0.352
012
1.000 (25.40)
0.250 (6.35)
1.613
013
1.180 (29.97)
0.062 (1.57)
0.472
1/
"X" in the PIN shall be replaced by the applicable material type. Complete PIN example: M83528/009A001.
2/
Dimensions are in inches; metric equivalents are given in parenthesis and are for general information only.
3/
Tolerance shall be as follows:
Tolerance
Dimensions
Under .101 (2.57)
± .005 (0.13)
.101 to .200 (2.57 to 5.08)
± .008 (0.20)
.201 to .300 (5.10 to 7.62)
± .010 (0.25)
.301 to .500 (7.62 to 12.70)
± .015 (0.38)
Over
.500 (12.70)
± .020 (0.51)
4/
For calculation of volume resistivity (for reference only).
2
