TABLE I. Dash numbers and delay characteristics at +25°C, Vcc = 5.00 ±.01 volts.
Delay and tolerances (ns)
Dash
number
Tap 1
Tap 2
Tap 3
Tap 4
Tap 5
Tap 6
Tap 7
Tap 8
Tap 9
Tap 10
Pin 13
Pin 3
Pin 12
Pin 4
Pin 11
Pin 5
Pin 10
Pin 6
Pin 9
Pin 8
001
5 ±2 ns
10 ±2 ns
15 ±2 ns
20 ±2 ns
25 ±2 ns
30 ±2 ns
35 ±2 ns
40 ±2 ns
45 ±5%
50 ±5%
002
7.5 ±2 ns
15 ±2 ns
22.5 ±2 ns
30 ±2 ns
37.5 ±2 ns
45 ±5%
52.5 ±5%
60 ±5%
67.5 ±5%
75 ±5%
003
10 ±2 ns
20 ±2 ns
30 ±2 ns
40 ±2 ns
50 ±5%
60 ±5%
70 ±5%
80 ±5%
90 ±5%
100 ±5%
004
12.5 ±2 ns
25 ±2 ns
37.5 ±2 ns
50 ±5%
62.5 ±5%
75 ±5%
87.5 ±5%
100 ±5%
112.5 ±5%
125 ±5%
005
15 ±2 ns
30 ±2 ns
45 ±5%
60 ±5%
75 ±5%
90 ±5%
105 ±5%
120 ±5%
135 ±5%
150 ±5%
006
17.5 ±2 ns
35 ±2 ns
52.5 ±5%
70 ±5%
87.5 ±5%
105 ±5%
122.5 ±5%
140 ±5%
157.5 ±5%
175 ±5%
007
20 ±2 ns
40 ±2 ns
60 ±5%
80 ±5%
100 ±5%
120 ±5%
140 ±5%
160 ±5%
180 ±5%
200 ±5%
008
25 ±2 ns
50 ±5%
75 ±5%
100 ±5%
125 ±5%
150 ±5%
175 ±5%
200 ±5%
225 ±5%
250 ±5%
009
30 ±2 ns
60 ±5%
90 ±5%
120 ±5%
150 ±5%
180 ±5%
210 ±5%
240 ±5%
270 ±5%
300 ±5%
010
35 ±2 ns
70 ±5%
105 ±5%
140 ±5%
175 ±5%
210 ±5%
245 ±5%
280 ±5%
315 ±5%
350 ±5%
011
40 ±2 ns
80 ±5%
120 ±5%
160 ±5%
200 ±5%
240 ±5%
280 ±5%
320 ±5%
360 ±5%
400 ±5%
012
45 ±5%
90 ±5%
135 ±5%
180 ±5%
225 ±5%
270 ±5%
315 ±5%
360 ±5%
405 ±5%
450 ±5%
013
50 ±5%
100 ±5%
150 ±5%
200 ±5%
250 ±5%
300 ±5%
350 ±5%
400 ±5%
450 ±5%
500 ±5%
014
60 ±5%
120 ±5%
180 ±5%
240 ±5%
300 ±5%
360 ±5%
420 ±5%
480 ±5%
540 ±5%
600 ±5%
015
70 ±5%
140 ±5%
210 ±5%
280 ±5%
350 ±5%
420 ±5%
490 ±5%
560 ±5%
630 ±5%
700 ±5%
016
80 ±5%
160 ±5%
240 ±5%
320 ±5%
400 ±5%
480 ±5%
560 ±5%
640 ±5%
720 ±5%
800 ±5%
017
90 ±5%
180 ±5%
270 ±5%
360 ±5%
450 ±5%
540 ±5%
630 ±5%
720 ±5%
810 ±5%
900 ±5%
018
100 ±5%
200 ±5%
300 ±5%
400 ±5%
500 ±5%
600 ±5%
700 ±5%
800 ±5%
900 ±5%
1000 ±5%
