A-A-55485D
3.5 Feet. Unless otherwise specified in the applicable CID sheet, feet shape may be either cylindrical or
spherical at the option of the manufacturer.
3.6 Gate protrusion. Gate protrusion (filling point of mold) shall not exceed .010 inch (0.25 mm) over the
maximum outside diameter of the pad.
3.7 Through-hole flash. For parts made of all materials except DAP, the flash ring shall not extend into
any through-hole more than .005 inch (0.13 mm). The maximum flash ring for DAP parts shall be
.002 inch (0.05 mm).
3.8 Through-hole countersink. A countersink is optional at the discretion of the manufacturer. If
provided, the dimensions of the countersink shall be as specified in the applicable CID specification
sheet.
3.9 Marking. Mounting pads supplied to this CID shall be marked with the manufacturer's (MFR's)
standard commercial PIN. (NOTE: The part number marked on the unit pack shall be the CID PIN.)
3.10 Recycled, recovered, or environmentally preferable materials. Recycled, recovered, or
environmentally preferable materials should be used to the maximum extent possible provided that the
material meets or exceeds the operational and maintenance requirements, and promotes economically
advantageous life cycle costs.
3.11 Workmanship. Mounting pads shall be processed in such a manner as to be uniform in quality and
shall be free from other defects that will affect life, serviceability, or appearance.
TABLE I. Materials.
Applicable CID sheet
Material code
Material
Reference document
A-A-55485/
A
Acetal, plastic molding
Polybutytherephthalate (PBT)
C
N/A
thermoplastic polyester 30%
nominal glass fiber, flame
retardant or equivalent
Diallyl phthalate (DAP),
D
N/A
thermosetting, short glass fiber
filler, general purpose
ASTMD6779 Standard
N
Nylon
Classification System for
Polyamide Molding and
Extrusion Materials , table
PA; PA0110
Polyphenylene sulfide,
S
PPS000G40A43443EA117ED
041EE020
4. REGULATORY REQUIREMENTS. The offeror/contractor is encouraged to use recovered materials to
the maximum extent practicable, in accordance with paragraph 23.403 of the Federal Acquisition
Regulation (FAR).
2
