CONFIGURATION B
PIN
Material
Nominal
Maximum
Dimensions (see notes)
Applicable fuse
AA55507/
fuse
current
style per MIL-
A
B
C
C1
D
E
G
J
K
01-
diameter
rating (A)
PRF-15160
max
min
max
min
max
(dia)
(dia)
09
B
.250
30
.50
.23
.31
.63
.23
.34
.020
.131
.093
F01, F02, F03
(6.35)
(12.7)
(5.8)
(7.9)
(16.0)
(5.8)
(8.6)
(0.51)
(3.33)
(2.36)
10
B
.406
30
.80
.45
.44
.78
.36
.51
.0200
.196
.093
F07, F09, F10,
(10.31)
(20.3)
(11.2)
(11.2)
(19.8)
(9.1)
(13.0)
±.0025
(4.98)
(2.36)
F27, F28, F60
(0.508
±0.064)
NOTES:
1. Dimensions are in inches. Millimeters are in parentheses and are provided for general information only.
2. Unless otherwise specified, tolerances are ±.02 (0.5 mm) for two place decimals and ±.005 (0.13 mm) for three place decimals.
3. Solder lug terminal shall be formed integral with the fuse clip.
Figure 2. Configuration and dimensions, configuration B.
