INCH-POUND
MIL-DTL-83528/1E
19 November 2013
SUPERSEDING
MIL-DTL-83528/1D
15 November 2001
DETAIL SPECIFICATION SHEET
GASKETING MATERIAL, CONDUCTIVE, SHIELDING GASKET, ELECTRONIC,
ELASTOMER, EMI/RFI, CIRCULAR STRIP, .040 THROUGH .250 DIAMETER
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the relay described herein shall
consist of this specification and the latest issue of MIL-DTL-83528.
NOTES:
1. Dimensions are in inches; metric equivalents are given in .parenthesis and are for general information only.
2. Length shall be as specified on the purchase order.
3. Tolerance on flash shall be ± .008 (0.20 mm) on the extension and ± .005 (0.13 mm) on the thickness.
FIGURE 1. EMI/RFI circular strip gasket.
AMSC N/A
FSC 5999
