MIL-DTL-83528/1E
REQUIREMENTS:
Material: Type A, B, C, D, E, F, H, J, K, L, or M.
Part or Identifying Number (PIN): See table I.
Supersession information: See table II.
TABLE I. Dimensions.
Cross section 4/
PIN 1/
Dimension A
area (cm2)
M83528/001X
± .005 2/ 3/
001
.040 (1.02)
.008
002
.053 (1.35)
.014
003
.062 (1.57)
.020
004
.070 (1.78)
.025
005
.080 (2.03)
.032
006
.093 (2.36)
.043
007
.103 (2.62)
.053
008
.119 (3.02)
.072
009
.125 (3.18)
.079
010
.139 (3.53)
.099
011
.188 (4.78)
.179
012
.216 (5.49)
.236
013
.250 (6.35)
.316
1/
"X" in the PIN shall be replaced by the applicable material type. Complete PIN example: M83528/001A001.
2/
Tolerance shall be ± .008 for parts over .200 in diameter.
3/
Dimensions are in inches; metric equivalents are given in parenthesis and are for general information only.
4/
For calculation of volume resistivity (for reference only).
TABLE II. Supersession information.
PIN 1/
Superseded DESC Drawing
M83528/001X
PIN 85103X 1/
001
001
002
002
003
003
004
004
005
N/A
006
005
007
006
008
007
009
008
010
009
011
N/A
012
010
013
N/A
1/
"X" in the PIN indicates the applicable material type.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where changes from
the previous issue were made. This was done as a convenience only and the Government assumes no liability whatsoever for
any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the requirements of this document
based on the entire content irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents. This document references MIL-DTL-83528.
