MIL-DTL-83528/5E
REQUIREMENTS:
Material: Type A, B, C, D, E, F, H, J, K, L, or M.
Part or Identifying Number (PIN): See table I.
Supersession information: See table II.
TABLE I. Dimensions. 6/
PIN 1/
Cross Section Area
Dimension 6/
(cm2)
M83528/005X
B
C
001
.030 (.76)
.442 (11.23)
.0046
002
.030 (.76)
.577 (14.66)
.0046
003
.030 (.76)
.692 (17.58)
.0046
004
.030 (.76)
.817 (20.75)
.0046
005
.039 (.99)
.425 (10.80)
.0077
006
.048 (1.22)
.295 (7.49)
.0117
007
.050 (1.27)
.533 (13.54)
.0127
008
.051 (1.30)
.446 (11.33)
.0132
009
.057 (1.45)
.415 (10.54)
.0165
010
.063 (1.60)
.541 (13.74)
.0201
011
.063 (1.60)
.648 (16.46)
.0234
012
.068 (1.73)
.847 (21.51)
.0234
013
.068 (1.73)
1.182 (30.02)
.0234
014
.068 (1.73)
3.165 (80.39)
.0234
015
.070 (1.78)
.495 (12.57)
.0248
016
.070 (1.78)
.610 (15.49)
.0248
017
.070 (1.78)
.635 (16.13)
.0248
018
.070 (1.78)
.667 (16.94)
.0248
019
.070 (1.78)
.860 (21.84)
.0248
020
.070 (1.78)
1.230 (31.24)
.0248
021
.103 (2.62)
1.040 (26.42)
.0538
022
.103 (2.62)
1.612 (40.94)
.0538
023
.103 (2.62)
1.790 (45.47)
.0538
1/
"X" in the PIN shall be replaced by the applicable material type. Complete PIN example: M38528/005A001.
2/
Dimensions are in inches; metric equivalents are given in parenthesis and are for general information only.
3/
Tolerance on dimension B shall be ± .003 for parts with a diameter of .070 and below; ± .005 for diameters from
.101 to .200.
4/
Tolerance on dimension C shall be ± .010 for parts from .000 to 1.500, ± .015 for parts from over 1.500 to 2.500
± .020 for parts from over 2.500 to 4.500.
5/
For calculation of volume resistivity (for reference only).
6/
See MIL-DTL-83528/2 for additional sizes.
2
