MIL-PRF-83532/2C
TABLE II. Dash numbers and delay characteristics at �55�C and +125�C,
Vcc = 5.00 �.01 volts.
Delay and tolerances (ns)
Dash
number
Tap 1
Tap 2
Tap 3
Tap 4
Output
Pin 12
Pin 4
Pin 10
Pin 6
Pin 8
001
5 �3 ns
10 �3 ns
15 �3 ns
20 �3 ns
25 �3 ns
002
6 �3 ns
12 �3 ns
18 �3 ns
24 �3 ns
30 �3 ns
003
7 �3 ns
14 �3 ns
21 �3 ns
28 �3 ns
35 �3 ns
004
8 �3 ns
16 �3 ns
24 �3 ns
32 �3 ns
40 �3 ns
005
9 �3 ns
18 �3 ns
27 �3 ns
36 �3 ns
45 �8%
006
10 �3 ns
20 �3 ns
30 �3 ns
40 �3 ns
50 �8%
007
11 �3 ns
22 �3 ns
33 �3 ns
44 �8%
55 �8%
008
12 �3 ns
24 �3 ns
36 �3 ns
48 �8%
60 �8%
009
13 �3 ns
26 �3 ns
39 �3 ns
52 �8%
65 �8%
010
14 �3 ns
28 �3 ns
42 �8%
56 �8%
70 �8%
011
15 �3 ns
30 �3 ns
45 �8%
60 �8%
75 �8%
012
16 �3 ns
32 �3 ns
48 �8%
64 �8%
80 �8%
013
18 �3 ns
36 �3 ns
54 �8%
72 �8%
90 �8%
014
20 �3 ns
40 �3 ns
60 �8%
80 �8%
100 �8%
015
25 �3 ns
50 �8%
75 �8%
100 �8%
125 �8%
016
30 �3 ns
60 �8%
90 �8%
120 �8%
150 �8%
017
35 �3 ns
70 �8%
105 �8%
140 �8%
175 �8%
018
40 �3 ns
80 �8%
120 �8%
160 �8%
200 �8%
019
45 �8%
90 �8%
135 �8%
180 �8%
225 �8%
020
50 �8%
100 �8%
150 �8%
200 �8%
250 �8%
021
55 �8%
110 �8%
165 �8%
210 �8%
275 �8%
022
60 �8%
120 �8%
180 �8%
240 �8%
300 �8%
023
70 �8%
140 �8%
210 �8%
280 �8%
350 �8%
024
80 �8%
160 �8%
240 �8%
320 �8%
400 �8%
025
90 �8%
180 �8%
270 �8%
360 �8%
450 �8%
026
100 �8%
200 �8%
300 �8%
400 �8%
500 �8%
027
120 �8%
240 �8%
360 �8%
480 �8%
600 �8%
028
140 �8%
280 �8%
420 �8%
560 �8%
700 �8%
029
160 �8%
320 �8%
480 �8%
640 �8%
800 �8%
030
180 �8%
360 �8%
540 �8%
720 �8%
900 �8%
031
200 �8%
400 �8%
600 �8%
800 �8%
1,000 �8%
3
